DOOR SPECIFICATION

  • Classen Hard construction (does not apply to PN22 and PN23 versions)
  • wide peripheral frame for PN22 and PN23 versions
  • milky-white toughened safety glass
  • possibility of shortening the leaf by 40 mm



Rebated door leaf (HK)

  • two silver screwed pintle hinges
  • mortice key lock, bathroom lock, cylinder lock, passage lock



Non-rebated door leaf (HB)

  • two openings for hinges for non-rebated door
  • magnetic lock: mortice key lock / bathroom lock / cylinder lock / passage lock

Dedicated door frames

HK:

  • steel adjustable door frame
  • steel fixed door frame
  • Standard 2 pack fixed door frame
  • adjustable door frame



HB:

  • steel fixed non-rebated door frame
  • steel adjustable non-rebated door frame

Notice

  • Door leaves 100’ and reinforced door leaves regardless of the size – 3 hinges.
  • Optional perforated chipboard, maximum leaf width 110, without Hard reinforcement.
  • Optional full chipboard, maximum leaf width 100, without Hard reinforcement.
  • Models PN22 and PN23 available only as 1-leaf, width 60′-100′. They are not available in a non-rebated version and are not available with the following frames: Adjustable 80, Standard 2-pack fixed and steel door frame.

Technical parameters

Variants

  • Single leaf
    60'-120'
  • Single and double leaf sliding system
  • Double leaf 120'-200' (HB is not included)
  • Prepared for shortening by 40mm

Glazing

  • Safety glass, toughened, white

Details

  • Frame profile

Additional options

Ventilation

  • Ventilation undercut
  • Ventilation undercut 15 mm (recuperation)
  • Ventilation sleeves PVC with woodgrain foil - CPL
  • PVC ventilation grille: white, grey, brown, beige
  • Aluminium ventilation grille
  • Steel kick-plate with ventilation grille

Construction

  • Third hinge
  • Perforated chipboard
  • Full chipboard
  • Non-rebated door leaf
  • Door leaf 100'
  • Door leaf 110'
  • Door leaf 120’
  • Door leaf - model PN22
  • Door leaf - model PN23
  • Sliding and passive door leaf

Glazing

  • Bullseye 35 ml - white glass
  • Bullseye 35 tr - transparent glass
  • Transparent glass
    for models 2-5

Accessories

  • Top steel panel - one-sided
  • Top steel panel - double-sided
  • Bottom steel panel, full - one-sided
  • Bottom steel panel, full - double-sided
  • Falling threshold
